The MAX2256XAEVKIT# is an evaluation and development kit for Maxim Integrated's industrial-grade digital isolator and interface IC families. The kit supports evaluation of the MAX22163–MAX22166 (reinforced isolators), MAX22563–MAX22566 (high-speed isolators), and MAX22663–MAX22666 (isolated gate drivers) product lines. Designed for engineers developing isolated power delivery, motor control, industrial automation, and power conversion applications, the kit includes reference schematics, PCB layouts, and firmware examples to accelerate design cycles. Typical use cases include motor drives, solar inverters, industrial power supplies, and CAN/RS-485 isolated communication networks requiring robust noise immunity and galvanic isolation in harsh electrical environments. Part Number: MAX2256XAEVKIT#; compatible with standard development platforms and bench instrumentation.
This kit is tested and guaranteed; available via quote from G5 Network Group.
