The Juniper P1-PTX-24-10G-W-SFPP is a 24-port 10 Gigabit Ethernet physical interface card designed for the Juniper PTX Series routing platforms. This line card provides 24 SFP+ ports supporting 10Gbps throughput per port, delivering 240Gbps aggregate bandwidth and enabling flexible LAN/WAN connectivity in carrier-class networks. The card integrates seamlessly with PTX1000, PTX3000, and PTX5000 chassis platforms, supporting a mix of single-mode and multi-mode fiber optics through standard SFP+ transceiver modules. Typical deployment scenarios include carrier backbone networks, data center interconnect, service provider edge routing, and high-throughput enterprise WAN applications requiring dense 10G port density.
The P1-PTX-24-10G-W-SFPP line card is fully compatible with Junos OS and supports standard routing protocols including BGP, OSPF, and IS-IS. Field-replaceable design allows hot-swap installation without service interruption. Part number P1-PTX-24-10G-W-SFPP is interchangeable across supported PTX platforms, providing modular scaling for network growth.
Tested and guaranteed. Available via quote from G5 Network Group.
